MegaRAID FastPath software provides high-performance I/O acceleration for SSD-based virtual drives by using a low latency I/O path to increase the maximum I/O per second (IOPS) capability of the controller. This feature boosts the performance of applications with a highly random data storage access pattern, such as transactional databases.
• MegaRAID flash cache protection
MegaRAID flash cache protection uses NAND flash memory, which is powered by a CacheVault Power Module supercapacitor, to protect data that is stored in the controller cache. This module eliminates the need for a lithium-ion battery, which is commonly used to protect DRAM cache memory on PCI RAID controllers. To avoid the possibility of data loss or corruption during a power or server failure, flash cache protection technology transfers the contents of the DRAM cache to NAND flash using power from the offload power module. After the power is restored to the RAID controller, the content of the NAND flash is transferred back to the DRAM, which is flushed to disk.
• MegaRAID SafeStore support for self-encrypting drive (SED) services
MegaRAID SafeStore encryption services offer instant secure erase and local key management for self-encrypting drives. This technology represents a step forward in securing data on a disk drive from any unauthorized access or modification resulting from theft, loss, or repurposing of drives. Instant secure erase permanently removes data when repurposing or decommissioning SEDs. SafeStore local key management provides the necessary management and protection of SEDs by using a simple pass phrase, security key identifier, and security key file that can be set and applied to all SEDs that are assigned to a RAID adapter. This feature removes the complexity of managing each SED’s unique encryption key, and it essentially relieves the administrator of most of the daily tasks of securing data.
Technical specifications
• PCIe 4.0 x8 host interface, also compatible with a PCIe 3.0 host interface
• 12 Gbps SAS/SATA RAID controllers
• 8GB of integrated flash-backed cache
• Connectivity for 32 internal SAS or SATA drives
• Support for intermixing SAS and SATA HDDs and SSDs. Mixing SAS and SATA drives in the same array is not supported. Mixing of HDDs and SSDs in the same array is not supported. Support for intermixing of 12 Gbps and 6 Gbps drives.
• Support for RAID 0, 1, 10, 5, 50, 6 and 60 standard
• Support for JBOD (non-RAID) drive state
• Support for logical drive sizes greater than 2 TB
• Configurable stripe size up to 1 MB Supports 512e, 512n and 4K sector formatted drives
• Supports UNMAP command for SAS SSDs (JBOD and RAID volumes)
• Supports TRIM command for SATA SSDs (JBOD) Compliant with Disk Data Format (DDF) configuration on disk (CoD).
Specification
Model
RAID 940- 32i 8GB
PN
4Y37A09733
Drive interface
SAS, SATA
Ports
32
Connectors
Four x8 SFF8654
Device type
HDD, SED, SSD
Port interface
12 Gb SAS
Cache
8GB (Standard)
Host interface
PCIe 4.0 x8
SAS Controller
SAS3916 + SAS35x36R expander
Cache Memory Options
Optional CacheVault Flash Module (LSICVPM05)
RAID levels
0, 1, 10, 5, 50, 6, 60
