Original LSI 9265-8i LSI00277 LSI00278 sas array card Megaraid LSI raids LSIiBBU09

Original LSI 9265-8i LSI00277 LSI00278 sas array card Megaraid LSI raids LSIiBBU09

High Performance 6Gb/s PCI Express SATA+SAS RAID Controller

Model	LSI 9265-8i
Part Number	LSI00277 LSI00278
SAS Controller	LSI SAS2208
Battery Backup Unit	LSIiBBU09
Warranty	3 years

Inquire Now

Product Details

LSI SAS 9265-8i LSI00277 LSI00278 6GB/s RAID CARD

Key Features

■ Eight internal 6Gb/s SATA+SAS ports

■ Two Mini-SAS internal connectors (SFF8087)

■ LSISAS2208 Dual- core 6Gb/s ROC

– x2 800MHz PowerPC Processors

■ 1GB DDRIII cache memory

■ Optional heat-tolerant battery backup

■ RAID Levels 0, 1, 5, 6, 10, 50 and 60

Key Advantages

■ Unmatched RAID performance

■ Connect up to 128 3Gb/s and 6Gb/s SATA and SAS hard drives or SSDs

■ Optimizes solid-state storage deployments

■ Heat-tolerant battery backup option (LSIiBBU09)

■ Support for LSI Advanced Software Options

Specification

Model	LSl 9265-8i
Single Pack	LSI00277
Kit	LSI00278
Connectors	Two Mini-SAS SFF-8087 internal connector
Device Support	Up to 128 SATA and/or SAS hard drives and SSDs
Data Transfer Rates	Up to 6 Gb/s per port
Cache Memory	1 GB 1333MHz DDRIII SDRAM
Host Bus Type	x8 lane PCI Express 2.0 Compliant
l/0 Processor/SAS Controller	LSISAS2208 Dual-Core RAID on Chip (ROC)
RAID levels	0，1，5，6，10，50，60
Physical Dimensions	MD2 Low profile (6.6” X 2.536”)
Availability	In Stock
