Advanced configuration and power interface(ACPI); Wake on LAN*(WoL); Preboot ExecutionEnvironment(PXE)
Remote Management Support
PROSet Utility for Microsoft* Device Manager
Advanced cable diagnostics
Benefits
High performance and reliability; low power
Delivers increased performance while significantlv reducing CPU usage
Designed for high performance on PCl Express desktop architecture while maintaining compatibility with PCl applications
Reduces deployment and training costs and enables easy, quick migrationto Gigabit Ethernet
Automatically compatible with Ethernet, Fast Ethernet, and Gigabit Ethernet networks
Enables widespread deployment
Enables low-power consumption, remote wake, and remote booting
Reduces support costs with remote management based on industry-wide standards
Provides point-and-click power over individual adapters, advanced adapter features,connection teaming, and virtual local area network (VLAN) confiquration
Dynamically tests and reports network problems (error rate, cable length) and automatically compensatesfor cable issues (cross-over cable, wrong pin-out/polarity)
Specification
Product P/N
EXPI9301CT
Connectorst
R45
Product Codes
EXPI9301CT EXPI9301CTBLK
Data rate supported per port
10, 100, and 1000 Mbps
Bus type
PCI Express 1.1 (2.5 GT/s)
Bus width
x1 lane PCI Express operable in x1, x4, x8, x16 slots
Bus speed (x1, encoded rate)
2.5 Gbps uni-directional; 5 Gbps bi-directiona
Interrupt levels
INTA,MSI,MSI-X
IEEE support
802.3z*
Hardware certifications
FCC B,UL,CE, VCCI,BSML, CTICK,MIC
Controller-processor
82574L
Typical power consumption
1.9 W
Operating temperature
0°C to 55° C(32°F to 131°F)
Storage temperature
-40°C to 70°C(-40°F to 158°F)
Storage humidity
90% non-condensing relative humidity at 35°C
Availability
In Stock
